main product photo

Orange Pi PC PLUS

9,438,000 ریال
اتمام موجودی
افراکد
501010011
قیمت ها به ریال می باشد
شکست قیمتقیمت واحدقیمت کل
109,249,24092,492,400
509,064,440453,222,000
1008,883,120888,312,000
هنگامی که این محصول در انبار موجود است به من اطلاع دهید
موجود شد خبر بده
توضیحات بیشتر
Hardware specification:
CPU: H3 Quad-core Cortex-A7 H.265/HEVC 4K
GPU: ·Mali400MP2 GPU @600MHz ·Supports OpenGL ES 2.0
Memory (SDRAM): 1GB DDR3 (shared with GPU)
Onboard Storage: TF card (Max. 32GB) / MMC card slot - 8GB EMMC Flash
Onboard Network: 10/100 Ethernet RJ45
Video Input: A CSI input connector Camera; Supports 8-bit YUV422 CMOS sensor interface, Supports CCIR656 protocol for NTSC and PAL, Supports SM pixel camera
sensor, Supports video capture solution up to 1080p@30fps
Audio Input:
MIC Video Outputs: Supports HDMI output with HDCP, Supports HDMI CEC, Supports HDMI 30 function, Integrated CVBS, Supports simultaneous output of HDMI and CVBS Audio Output: 3.5 mm Jack and HDMI
Power Source: DC input, USB OTG input don't supply power
USB 2.0 Ports: Three USB 2.0 HOST, one USB 2.0 OTG
Buttons: Power button
Low-level peripherals: 40 Pins Header GPIO(1x3)
pin: UART, ground.
LED: Power led & Status led
Key: IR input,POWER
Supported OS: Android Lubuntu, Debian Image
Product size: 85mm × 55mm Weight: 70g
مشخصات فنی
نام کالاOrange Pi PC PLUS
شرح کالا
Hardware specification:
CPU: H3 Quad-core Cortex-A7 H.265/HEVC 4K
GPU: ·Mali400MP2 GPU @600MHz ·Supports OpenGL ES 2.0
Memory (SDRAM): 1GB DDR3 (shared with GPU)
Onboard Storage: TF card (Max. 32GB) / MMC card slot - 8GB EMMC Flash
Onboard Network: 10/100 Ethernet RJ45
Video Input: A CSI input connector Camera; Supports 8-bit YUV422 CMOS sensor interface, Supports CCIR656 protocol for NTSC and PAL, Supports SM pixel camera
sensor, Supports video capture solution up to 1080p@30fps
Audio Input:
MIC Video Outputs: Supports HDMI output with HDCP, Supports HDMI CEC, Supports HDMI 30 function, Integrated CVBS, Supports simultaneous output of HDMI and CVBS Audio Output: 3.5 mm Jack and HDMI
Power Source: DC input, USB OTG input don't supply power
USB 2.0 Ports: Three USB 2.0 HOST, one USB 2.0 OTG
Buttons: Power button
Low-level peripherals: 40 Pins Header GPIO(1x3)
pin: UART, ground.
LED: Power led & Status led
Key: IR input,POWER
Supported OS: Android Lubuntu, Debian Image
Product size: 85mm × 55mm Weight: 70g
سازندهOrange Pi
اندازهندارد
نوع کالاماژول
MOQ1
